Code Verification for Practical Machine Architectures
This is the project page for the DARPA CRASH effort at the University
of Texas at Austin.
Download
The software for the x86isa project developed over the course of
this program is available for download (licensed under BSD 3Clause)
as a part of the ACL2 community books.
Here is the github page: ACL2
System and Books as Maintained by the Community.
The x86isa books are located
at: acl2/books/projects/x86isa and documentation is
available here.
People
Keshav Kini
(PhD Student)
J Moore
(Professor)

Ben Selfridge
(PhD Student)

Nathan Wetzler
(PhD Candidate)

Previous Members of the CRASH Team:
Natahlie Beavers
(Undergraduate Student)

Soumava Ghosh
(Masters Student)

Robert Krug
(Research Engineering/
Scientist Associate IV)

Corbyn Salisbury
(Undergraduate Student)
Théo Zimmermann
(CS Graduate Student)
Problem Description
With pervasive use of software artifacts in every aspect of human
life, the cost of malfunctioning software today is staggering. Formal
methods have shown significant promise to improve software reliability
dramatically. However, deductive or theorem proving solutions, based
on humanguided, semiautomatic mechanical reasoning often involve
prohibitive manual effort, while fully automatic approaches based on
decision procedures can quickly run out of available time and memory.
Better tool suites and methodologies are needed in order to achieve
the promise of formal methods for achieving correct, resilient
computing systems. This project focuses on the creation of formal
tools for code verification, in particular for x86 machine code, with
a related goal of improving the ACL2 theorem proving environment.
Research Goals
 Develop an executable, formal specification for a significant
subset of the x86 instruction set architecture (ISA). Our focus is on
the 64bit mode of Intel's IA32e mode. Our current version of the
model has a simulation speed of ~3.3 million instructions/second in
its programmerlevel mode (where we operate at the level of linear
memory) and and ~920,000 instructions/second with a twolevel page
table configuration in its systemlevel mode (where we operate at the
level of physical memory). We support almost 120 generalpurpose
instructions (221 opcodes) and 80 SSE/SSE2 instructions.
 Construct a mechanized proof assistant for x86 binary code. The
development of a formal specification, discussed above, is a critical
step towards reaching this goal. The efficient executability of that
specification is also critical, in order to validate the model by
cosimulation against actual x86 execution. We will use
the ACL2
theorem prover to carry out code proofs, both using BDD/SATbased
symbolic simulation and by developing methods based on generalpurpose
theorem proving techniques, especially rewriting and induction.
 Improve
the ACL2
theorem proving environment. This is a longterm goal that our
research group continues to pursue. ACL2 is our core formal
verification technology, so improvements to ACL2 support the research
goals discussed above, such as the
``abstract stobjs'' feature.
 Develop tools to gain confidence in satisfiability (SAT) solvers.
Researchers develop high performance applications called SAT solvers
to efficiently solve satisfiability problems, and any problem that can
be encoded into a Boolean formula can be investigated with SAT
solvers. It is easy to check a solution to a satisfiability problem
if one can be found. However, if a solver outputs that a formula is
unsatisfiable, we must trust that the solver exhausted all possible
assignments. Existing verification tools cannot verify all techniques
used in stateoftheart solvers.
 Create automated, sophisticated satisfiability encodings with
respect to software verification. The encoding of problems, such as
software verification, into Boolean formulas has a huge impact on the
performance of SAT solvers. We will develop techniques that, given a
certain highlevel description, will make a high quality translation
of the problem into a Boolean formula.
Technical Approach
Our technical approach to x86 code verification is based on building a
formal interpreterstyle model for the x86 instruction set
architecture (ISA) in the language of
the ACL2 theorem
prover. By making our model efficient to execute on concrete
data, we are validating our model by cosimulation against execution
on an actual x86 processor.
Our previous work suggests that we can build ACL2 proof infrastructure
on top of that model, though the complexity of the x86 architecture
presents new challenges. In support of this work, we will continue to
improve the ACL2 proof environment. We will also employ symbolic
simulation, which is an effective approach to software verification,
and develop capabilities to apply, in a sound way, BDDs and SAT
techniques, which together are the most used techniques for symbolic
simulation.
Dissemination of Research Results
We intend to make our x86 ISA specification and associated proof
technology available from this page by the end of 2014 (sooner
upon request from DARPA). A much simpler
model is based on the y86 ISA, developed in the textbook Computer Systems: A Programmer's
Perspective, 2/E by Bryant and O'Hallaron (in particular, Chapter 4).
We provide here an early version of our y86
model; for a recent version, see
directory models/y86/
in the ACL2 Community
Books.
SOFTWARE
The ACL2 theorem proving system has been publicly available for about
two decades, and is currently available
from the ACL2
home page. It is in regular use at several companies, including
AMD, Centaur Technology (VIA Technology), IBM, and Rockwell Collins.
It has and continues to be used by U.S. government personnel, some of
whom have expressed interest in our x86 model in particular.
Visit the ACL2
home page to obtain the latest version of ACL2 and to view that system's
documentation.
PUBLICATIONS
Authors from our CRASH group at UT Austin are shown in bold
font.
 WellFormedness Guarantees for ACL2 Metafunctions and Clause
Processors.
Matt Kaufmann and J Strother Moore.
DIFTS'15: International
Workshop on Design and Implementation of Formal Tools and Systems.
 Fourier Series Formalization in ACL2(r)
Cuong K. Chau, Matt Kaufmann, and Warren A. Hunt,
Jr.
Proceedings of ACL2 Workshop 2015.
 Efficient,
MechanicallyVerified Validation of Satisfiability Solvers.
Nathan David Wetzler.
PhD dissertation, The University of Texas at Austin, May 2015.
 Expressing symmetry breaking in DRAT proofs
Marijn J. H. Heule, Warren A. Hunt, Jr., and Nathan
Wetzler
International Conference on Automated Deduction (CADE), volume 9195 of
LNCS, 2015.
 Simulation and Formal Verification of x86 MachineCode
Programs that make System Calls.
Shilpi Goel, Warren A. Hunt, Jr., Matt Kaufmann,
and Soumava Ghosh.
Proceedings of FMCAD 2014, Formal Methods in ComputerAided Design,
2014.
 Efficient Extraction of Skolem Functions from QRAT
Proofs.
Marijn J. H. Heule, Martina Seidl, and Armin Biere.
Proceedings of FMCAD 2014, Formal Methods in ComputerAided Design,
2014.
 Validating Unsatisfiability Results of Clause Sharing
Parallel SAT Solvers.
Marijn J. H. Heule, Norbert Manthey, and Tobias Philipp.
Proceedings of PoS 2014, 5th Pragmatics of SAT workshop, 2014.
 Rough Diamond: An Extension of Equivalencebased Rewriting.
Matt Kaufmann and J Strother Moore.
Proceedings of ITP 2014, 5th Conference on Interactive Theorem
Proving, 2014.
 DRATtrim: Efficient Checking and Trimming Using
Expressive Clausal Proofs.
Nathan Wetzler, Marijn J. H. Heule, and Warren
A. Hunt, Jr..
International Conference on Theory and Applications of Satisfiability
Testing (SAT), 2014.
 Everything You Always Wanted to Know About Blocked Sets
(But Were Afraid to Ask).
Tomas Balyo, Andreas Frohlich, Marijn J. H. Heule, and Armin Biere.
International Conference on Theory and Applications of Satisfiability
Testing (SAT), 2014.
 MUS Extraction using Clausal Proofs.
Anton Belov, Marijn J. H. Heule, and Joao MarquesSilva.
International Conference on Theory and Applications of Satisfiability
Testing (SAT), 2014.
 A Unified Proof System for QBF Preprocessing
Marijn J. H. Heule, Martina Seidl, and Armin Biere.
7th International Joint Conference on Automated Reasoning (IJCAR
2014).
 Enhancements to ACL2 in Versions 6.2, 6.3, and 6.4.
Matt Kaufmann and J Strother Moore.
ACL2 Workshop 2014.
 IndustrialStrength Documentation for ACL2.
Jared Davis and Matt Kaufmann.
ACL2 Workshop 2014.
 Blocked Clause Decomposition.
Marijn J. H. Heule and Armin Biere.
LPAR19, Logic for Programming Artificial Intelligence and Reasoning, 2014.
 Trimming while Checking Clausal Proofs.
Marijn J. H. Heule, Warren A. Hunt, Jr., and Nathan Wetzler.
FMCAD 2013, 13th Conference on Formal Methods in ComputerAided Design.
 Bridging the Gap Between Easy Generation and Efficient Verification of Unsatisfiability Proofs.
Marijn J. H. Heule, Warren A. Hunt Jr., and Nathan Wetzler.
Software Testing, Verification, and Reliability (STVR): Special Issue
on Tests and Proofs, 2014.
 Guided Merging of Sequence Diagrams.
Magdalena Widl, Armin Biere, Petra Brosch, Uwe Egly, Marijn Heule, Gerti Kappel, Martina Seidl, and Hans Tompits.
Conference on Software Language Engineering 2012.
 Concurrent CubeandConquer.
Peter van der Tak, Marijn J.H. Heule, and Armin Biere.
Pragmatics of SAT 2012.
 A Formal Model of a Large Memory that Supports Efficient Execution.
Warren A. Hunt, Jr. and Matt Kaufmann.
Formal Methods in ComputerAided Design 2012.
 Towards a Formal Model of the X86 ISA.
Warren A. Hunt, Jr. and Matt Kaufmann.
Technical Report, Dept. of Computer Science, University of Texas at Austin.
 Automated Reencoding of Boolean Formulas.
Norbert Manthey, Marijn J. H. Heule and Armin Biere.
Haifa Verification Conference 2012.
 Revisiting Hyper Binary Resolution.
Marijn J. H. Heule, Matti Jarvisalo, and Armin Biere.
Conference on Integration of Artificial Intelligence and Operations Research techniques in Constraint Programming (2013).
 Enhancements to ACL2 in Versions 5.0, 6.0, and 6.1.
Matt Kaufmann and J Strother Moore.
ACL2 Workshop 2013, Electronic Proceedings in Theoretical Computer Science.
 A Parallelized Theorem Prover for a Logic with Parallel Execution.
David L. Rager (now at Oracle), Warren A. Hunt, Jr., and Matt Kaufmann.
ITP 2013, 4th Conference on Interactive Theorem Proving.
 Abstract Stobjs and Their Application to ISA Modeling.
Shilpi Goel, Warren A. Hunt, Jr., and Matt Kaufmann.
ACL2 Workshop 2013, Electronic Proceedings in Theoretical Computer Science.
 Automated Code Proofs on a Formal Model of the X86
Shilpi Goel and Warren A. Hunt, Jr.
VSTTE 2013 (Verified Software: Theories, Tools, and Experiments).
 Verifying Refutations with Extended Resolution.
Marijn J. H. Heule, Warren A. Hunt, Jr., and Nathan Wetzler.
Conference on Automated Deduction 2013.
 Mechanical Verification of SAT Refutations with Extended Resolution.
Nathan Wetzler, Marijn J. H. Heule, and Warren A. Hunt, Jr.
ITP 2013, 4th Conference on Interactive Theorem Proving.
 A SAT Approach to CliqueWidth.
Marijn J. H. Heule and Stefan Szeider.
International Conference on Theory and Applications of Satisfiability Testing (2013).
